HYDROWAVE 75T
The HYDRO WAVE pump is designed to meet the most demanding needs in construction, mining, and industrial applications. Built to last, it delivers high pumping capacity even with liquids containing solid materials, gravel, and abrasive substances.
When the job gets tough, our pump gets going
Download Technical Sheet
POWER
7.5 HP (5.5 kW)
MAX HEAD
23 m
MAX FLOW
1900 lpm
Starting from
Related Kit
Discover related kit solutions for this product
Item Title
Item Title
Item Title
Features
High chrome steel closed impeller
The high chrome steel closed impeller offers significant advantages in terms of durability, wear resistance, and performance.
The high chrome steel is extremely resistant to erosion, abrasion, and impact.
The closed impeller design is more hydraulically efficient than semi-open or open impellers, especially in cleaner fluids or fluids with moderate solids.
Technical data
Dimensions
HEIGHT
633
mm
MAXIMUM DIMENSION (WIDTH)
324
mm
LOWER RUNNING WATER LEVEL
133
mm
DISCHARGE
4
"
WEIGHT
51.4
kg
Model
HP
kW
Inch
Q
(lpm)
0
200
800
1200
1900
Q
(m³/h)
0
20
40
80
114
HW-75_T
7.5
5.5
4"
H(m)
23
22.5
18.8
14.3
3
H(m)
23
22
20
12.5
3
Parts and Material List
1
Discharge
AlSi7Mg
2
Upper Cover
AlSi7Mg
3
Motor Cover
AlSi7Mg
4
Upper Bearing Bracket
EN-GJL-200
5
Lower Bearing Bracket
AlSi7Mg
6
Seal Bracket
AlSi7Mg
7
Impeller
High Chrome Steel
8
Pump Casing
EN-GJL-200
9
Strainer
AISI 304
10
Handle
Steel/NBR
11
Outer Casing
AISI 304
12
Motor Frame
AISI 304
20
Power Cable
H07RN-F / SJTOW / STOW
22
Protector
KLIXON
24.1
Upper Bearing
NTN/TPI
24.2
Lower Bearing
NTN/TPI
25
Rotor and Shaft
AISI 410
28
Stator
-
29
Mechanical Seal
Upper:CA/CE
-
-
Lower:SIC/SIC
30
Lip Seal
NBR
31
Wearing Plate
Nylon PA 66
Specifications
Limits of Use
Liquid Temp.
0-40°C (32-104°F)
Application
As suggested application in the section below
Type
Frequency
50Hz
Motor
2P (2850RPM) . Dry Motor
Insulation
Class F
Protection
IP 68
Protector
Auto-Cut
Bearing
Ball Type
Mech. Seal
Dual Mechanical Seal
Material
Shaft
AlSi 410
Motor Frame
AlSi 304
Motor Cover
AlSi7Mg
Cable
H07RN-F / SJTOW / STOW
Impeller
High Chrome Steel
Pump Casing
EN-G JL-200
Mechanical Seal
Upper:CA/CE ; Lower:SIC/SIC
